— Pre-filter for gas sampling from processes with high dust levels — For cleaning purposes: pre-filter can be back-purged — With a deflector plate and a tube fitting for direct mounting on sample tube type SP2000/SS — For dust loads from 2 to 10 g/m3 — Connection: tube fitting with double cutting ring for tubes with Ø 25 mm OD — Length: 150 mm [≈ 0.5 ft] w/o connection and w/o deflector plate — Filter porosity: 20 µm — Sampling temperature: max. +600 °C [+1112 °F] — Material of sample-contacting parts: stainless steel Stainless steel pre-filter for retrofitting the SP2000 stainless steel tube, up to max. 600 °C The M&C pre-filters are used in combination with the M&C gas sample probes series SP for continuous gas sampling in processes with an increased level of dust. Pre‑filter type 20SS 150 for SP2000‑H, stainless steel filter with Swagelok® fitting for mounting to the SS sample tube, incl. protection shield, length: 150 mm, 30 mm OD, filter porosity: 20 µm, temperature: max. 600 °C, material: SS 316L
Технические характеристики
CharacteristicsSample typegasTechnologyprobeOther characteristicsstainless steel
