Thermal Conductivity Analyser 8866 is an analyzer for harsh environment that allows very accurate and stable in line analysis of a gas in a binary (or almost binary) mixture, taking advantage of its own specific thermal conductivity, respect to the background gas. The weatherproof and explosion proof 8866 is designed for field installation in the most severe conditions, minimizing the sample conditioning requirements. Measureable Gas Hydrogen [H2] Helium [He] Air [Air] Sulfur Dioxide [SO2] Acetylene [C2H2] Argon [Ar] Nitrogen [N2] Special 3-Ranges Calibration for Hydrogen Cooled Generators [TR] Carbon Dioxide [CO2] Nitrous Oxide [N2O] Methane [CH4] Main Features Extreme Roughness No inner moving parts Wet parts in AISI316 and glass Resistant to the most severe industrial environments High Performances Sensing unit temperature controlled Insensitive to ambient temperature variations Installation position and vibration don’t alter the accuracy and stability of the measure Available as 4-20 mA transmitter or combined with a powerful microprocessor-based control unit Easy Maintenance Modular construction Fast access to the inner PCB just unscrewing the housing cap Possibility to remove the entire sensing unit from the housing just by unscrewing 2 screws and leaving her housing connected to the sampling system.
Технические характеристики
CharacteristicsMeasured entitygas, hydrogen, nitrous oxideMeasured valuethermal conductivityConfigurationfor integration, modularProtection levelweatherproof, for harsh environmentsOther characteristicscontinuous, ATEX
