Технические характеристики
| Type | High Q.E. type |
|---|---|
| Tube Size | 30 x 30 mm |
| Photocathode Area Shape | Square |
| Photocathode Area Size | 18 x 18 mm |
| Wavelength (Short) | 300 nm |
| Wavelength (Long) | 700 nm |
| Wavelength (Peak) | 420 nm |
| Spectral Response Curve Code | 444K |
| Photocathode Material | Extended green bialkali |
| Window Material | Borosilicate glass |
| Dynode Structure | Metal channel |
| Dynode Stages | 10 |
| [Max. Rating] Anode to Cathode Voltage | 900 V |
| [Max. Rating] Average Anode Current | 0.1 mA |
| Anode to Cathode Supply Voltage | 800 V |
| [Cathode] Luminous Sensitivity Min. | 120 μA/lm |
| [Cathode] Luminous Sensitivity Typ. | 160 μA/lm |
| [Cathode] Blue Sensitivity Index (CS 5-58) Typ. | 14 |
| [Cathode] Radiant Sensitivity Typ. | 125 mA/W |
| [Anode] Luminous Sensitivity Min. | 80 A/lm |
| [Anode] Luminous Sensitivity Typ. | 320 A/lm |
| [Anode] Radiant Sensitivity Typ. | 2.5 x 105 A/W |
| [Anode] Gain Typ. | 2.0 x 106 |
| [Anode] Dark Current (after 30min.) Typ. | 2 nA |
| [Anode] Dark Current (after 30min.) Max. | 20 nA |
| [Time Response] Rise Time Typ. | 1.6 ns |
| [Time Response] Transit Time Typ. | 9.6 ns |
| [Time Response] Transit Time Spread Typ. | 0.35 ns |
| [Anode] Pulse Linearity (2% deviation) | 30 mA |
| [Anode] Pulse Linearity (5% deviation) | 60 mA |
