Технические характеристики
| Type | Head-on type |
|---|---|
| Tube Size | Dia.28 mm |
| Photocathode Area Shape | Round |
| Photocathode Area Size | Dia.10 mm |
| Wavelength (Short) | 300 nm |
| Wavelength (Long) | 850 nm |
| Wavelength (Peak) | 420 nm |
| Spectral Response Curve Code | 500K |
| Photocathode Material | Multialkali |
| Window Material | Borosilicate glass |
| Dynode Structure | Box-and-grid+Linear-focused |
| Dynode Stages | 11 |
| [Max. Rating] Anode to Cathode Voltage | 1500 V |
| [Max. Rating] Average Anode Current | 0.01 mA |
| Anode to Cathode Supply Voltage | 1000 V |
| [Cathode] Luminous Sensitivity Min. | 80 μA/lm |
| [Cathode] Luminous Sensitivity Typ. | 150 μA/lm |
| [Cathode] Red/White Ratio (R-68) Typ. | 0.2 |
| [Cathode] Radiant Sensitivity Typ. | 64 mA/W |
| [Anode] Luminous Sensitivity Typ. | 1500 A/lm |
| [Anode] Radiant Sensitivity Typ. | 6.4 x 105 A/W |
| [Anode] Gain Typ. | 1.0 x 107 |
| [Time Response] Rise Time Typ. | 1.7 ns |
| [Time Response] Transit Time Typ. | 26 ns |
| Notes | Anode dark count (Typ.) : 300 (s-1) Anode dark count (Max.) : 1000 (s-1) |
