Технические характеристики
| Type | Side-on type |
|---|---|
| Features | High sensitivity |
| Tube Size | Dia.28 mm |
| Photocathode Area Shape | Square |
| Photocathode Area Size | 8 x 24 mm |
| Wavelength (Short) | 185 nm |
| Wavelength (Long) | 900 nm |
| Wavelength (Peak) | 450 nm |
| Photocathode Material | Multialkali |
| Window Material | UV glass |
| Dynode Structure | Circular-cage |
| Dynode Stages | 9 |
| [Max. Rating] Anode to Cathode Voltage | 1250 V |
| [Max. Rating] Average Anode Current | 0.1 mA |
| Anode to Cathode Supply Voltage | 1000 V |
| [Cathode] Luminous Sensitivity Min. | 600 μA/lm |
| [Cathode] Luminous Sensitivity Typ. | 650 μA/lm |
| [Cathode] Blue Sensitivity Index (CS 5-58) Typ. | 14 |
| [Cathode] Red/White Ratio (R-68) Typ. | 0.45 |
| [Cathode] Radiant Sensitivity Typ. | 65 (at 800 nm) mA/W |
| [Anode] Luminous Sensitivity Min. | 1600 A/lm |
| [Anode] Luminous Sensitivity Typ. | 8500 A/lm |
| [Anode] Gain Typ. | 1.3 x 107 |
| [Anode] Dark Current (after 30min.) Typ. | 2 nA |
| [Anode] Dark Current (after 30min.) Max. | 10 nA |
| [Time Response] Rise Time Typ. | 2.2 ns |
| [Time Response] Transit Time Typ. | 22 ns |
| [Time Response] Transit Time Spread Typ. | 1.2 ns |
