Технические характеристики
| Type | Head-on type |
|---|---|
| Features | Compact size |
| Tube Size | Dia.13 mm |
| Photocathode Area Shape | Round |
| Photocathode Area Size | Dia.10 mm |
| Wavelength (Short) | 300 nm |
| Wavelength (Long) | 700 nm |
| Wavelength (Peak) | 420 nm |
| Spectral Response Curve Code | 400K |
| Photocathode Material | Extended green bialkali |
| Window Material | Borosilicate glass |
| Dynode Structure | Linear-focused |
| Dynode Stages | 10 |
| [Max. Rating] Anode to Cathode Voltage | 1250 V |
| [Max. Rating] Average Anode Current | 0.1 mA |
| Anode to Cathode Supply Voltage | 1000 V |
| [Cathode] Luminous Sensitivity Min. | 120 μA/lm |
| [Cathode] Luminous Sensitivity Typ. | 160 μA/lm |
| [Cathode] Blue Sensitivity Index (CS 5-58) Typ. | 14 |
| [Cathode] Radiant Sensitivity Typ. | 105 mA/W |
| [Anode] Luminous Sensitivity Min. | 100 A/lm |
| [Anode] Luminous Sensitivity Typ. | 320 A/lm |
| [Anode] Gain Typ. | 2.0 x 106 |
| [Anode] Dark Current (after 30min.) Typ. | 1 nA |
| [Anode] Dark Current (after 30min.) Max. | 5 nA |
| [Time Response] Rise Time Typ. | 1.2 ns |
| [Time Response] Transit Time Typ. | 14 ns |
| [Time Response] Transit Time Spread Typ. | 1.4 ns |
| [Anode] Pulse Linearity (2% deviation) | 3 mA |
| [Anode] Pulse Linearity (5% deviation) | 12 mA |
