Технические характеристики
| Type | Head-on type |
|---|---|
| Tube Size | Dia.25 mm |
| Photocathode Area Shape | Round |
| Photocathode Area Size | Dia.22 mm |
| Wavelength (Short) | 300 nm |
| Wavelength (Long) | 650 nm |
| Wavelength (Peak) | 420 nm |
| Spectral Response Curve Code | 400K |
| Photocathode Material | Bialkali |
| Window Material | Borosilicate glass |
| Dynode Structure | Linear-focused |
| Dynode Stages | 8 |
| [Max. Rating] Anode to Cathode Voltage | 1500 V |
| [Max. Rating] Average Anode Current | 0.1 mA |
| Anode to Cathode Supply Voltage | 1300 V |
| [Cathode] Luminous Sensitivity Min. | 70 μA/lm |
| [Cathode] Luminous Sensitivity Typ. | 95 μA/lm |
| [Cathode] Blue Sensitivity Index (CS 5-58) Typ. | 11 |
| [Anode] Luminous Sensitivity Min. | 5 A/lm |
| [Anode] Luminous Sensitivity Typ. | 100 A/lm |
| [Anode] Gain Typ. | 1.0 x 106 |
| [Anode] Dark Current (after 30min.) Typ. | 5 nA |
| [Anode] Dark Current (after 30min.) Max. | 50 nA |
| [Time Response] Rise Time Typ. | 1 ns |
| [Time Response] Transit Time Typ. | 11 ns |
| [Time Response] Transit Time Spread Typ. | 0.27 ns |
