Технические характеристики
-Non-Ferrous Materials: Titanium construction. -Very-Fine Resolution: Can resolve down to 1.13 gram-force. -Extremely-High Strength: EDM wire-cut from grade 5 titanium. Maximum allowable single-axis overload values are 7.4 to 15.0 times rated capacities. -High Signal-to-Noise Ratio: Silicon strain gages provide a signal 75 times stronger than conventional foil gages. This signal is amplified, resulting in near-zero noise distortion. Typical Applications -Biomechanical research -Measurements in highly magnetic environments -Medical applications Single-Axis Overload Fxy — ±1500 N Fz — ±4600 N Txy — ±30 Nm Tz — ±40 Nm Stiffness (Calculated) X-axis & Y-axis forces (Kx, Ky) — 3.1×107 N/m Z-axis force (Kz) — 6.4×107 N/m X-axis & Y-axis torque (Ktx, Kty) — 4.5×103 Nm/rad Z-axis torque (Ktz) — 6.5×103 Nm/rad Resonant Frequency Fx, Fy, Tz — 4900 Hz Fz, Tx, Ty — 5000 Hz Physical Specifications Weight* — 0.0334 kg Diameter* — 27 mm Height* — 18.2 mm
