Description
Specifications:
- Volume: 5.0 cu ft
- Chamber Dimensions: 18 x 18 x 26.5 in
- Case Material: Enamel coated Steel
- Controller Type: Microprocessor
- Temperature Range (Metric): 30 to 75°C
- Material (Internal): Stainless Steel
- Temperature Uniformity: ±0.7 at 37°C
- Display: LED
- Insulation: 3 in. Thick Fiberglass
- Material: Steel
- Resolution: 0.1°C
Description:
Incubators with gravity flow circulation provide accurate, efficient heating for routine laboratory procedures: drying and staining of slides, paraffin embedding, tissue culture work, incubation of antibody tests, microbiological determinations, crystallization studies and more. Electrical receptacle inside (5A at 120V) to plug in a stirrer, shaker or other apparatus.
Easy to operate
- Microprocessor control
- Controls are conveniently located at the top of the incubator chamber
- Keypad with arrow keys to increase or decrease set point temperature in 0.1°C increments
- Overtemperature value is automatically set at 3°C above setpoint
- PID controller comes with fixed parameters so no tuning is required
- Circuit breaker protects incubator from power surges, battery backup
- Designed to stack two units
Big three-character LED display
- Digits display actual temperature to nearest 0.1°C
- Display shows current value for set point temperature
- HEAT indicator light cycles on and off to show when incubator heaters are on
- ALARM indicator lights up if temperature exceeds overtemperature limit, backup controller maintains temperature at 3°C above setpoint, safety backup built into software
Small, medium and large workload capacities
- Available in three chamber capacities
- Mounting holes at 2 in. (5cm) intervals on the chamber walls for shelf placement
- Small incubator holds a maximum of five shelves, medium incubator holds eight, and large incubator holds eleven
Low-maintenance incubators with inner and outer doors
- Cabinet has durable, enamel-coated steel exterior
- Extruded aluminum trim has acrylic powder coating
- Chamber is easy-to-clean stainless steel
- Low-watt-density heater elements are designed for long life
- Silicone gasket on outer door and 3 in. thick (7.6cm) fiberglass insulation throughout prevent heat loss
- Outer door opens to 180° for unhindered access and features two grabber-type latches
- Inner door is tempered glass
- Steel shelves are 17.37 in. wide and 16.75 in. front-to-back (44 x 42.5cm)
- Black synthetic rubber feet keep incubator from slipping and maintain a space between incubator and benchtop for ventilation
