The A-LINE™ M-LH-1T Fixed Lens Mount is a convenient and economical solution for mounting thin 1.0 inch (25.4 mm) lenses and beamsplitters. The 0.25 in. (6.4 mm) thick lens mount consists of a threaded holder with a retaining ring to hold the optic firmly, but gently. The holder incorporates an 8-32 threaded mounting hole for post mounting on English SP and MSP Series posts. The front of the holder also has a special 6 mm alignment hole, which can be used with GR Series Guide Rods for fast alignment of several A-LINE™ lens mounts. This product is also available in 10-piece saving pack M-LH-1T-PK.
Технические характеристики
- Type Fixed Lens Mount
- Optic Diameter 25.4 mm
- Edge Thickness (Te) 3 mm
- Optical Axis Height 31.8 mm
- Adjustments Fixed
- Optic Retaining Thread 1.035‐40
- Clear Aperture 22.9 mm
- Thread Type M4
