The ICON X WELD platform has been designed to combine small dimensions with a large and comfortable work area. The X axis easily allows the processing of multi-object pallets and makes it more productive than a fixed field model. Icon X is the right balance between versatility and price for most applications. Available in configuration suitable for Metal welding and Plastic welding applications. The system is equipped with a large working area (700 x 400mm) and an automatic door open on 3 sides with a large inspection window. All customer materials can be processed with ICON X thanks to the integration of the ideal LASER source for each application. 1. PRODUCTIVITY Compared to a fixed field system, ICON X allows you to move along the X axis to be able to process batches in pallets or paneling on large pieces. 2. WORK AREA AND MOTION The configuration with 2 motorized linear axes with strokes (X / Z) of up to 400mm, a rotary axis R and a worktable of 700 x 400 makes ICON X ready for the most demanding challenges. 3. SOURCES Possibility of integrating QCW, CW Fiber sources for metal welding and Diode sources for marking plastic parts. MATRIX – SOFTWARE SUITE Matrix is an advanced Software Suite developed thanks to thirty years of experience in Laser Marking, Engraving, Welding and Micromachining systems and ready for the challenges of Industry 4.0. It represents the state of the art of work functions and has the best man-machine interface on the market. This makes the training times of the operators practically nil and makes even more intense use pleasant.
Технические характеристики
CharacteristicsTechniquefiber laserOperational modeautomaticApplicationsfor metal, for plasticsPower
Max.: 500 W
Min.: 20 W
