The ISO-04-532-BB-W is used to protect a laser source from destabilizing feedback or actual damage from back-reflected light. This 532 nm free space optical isolator consists of a compact, cylindrically-shaped, magneto-optic device with a base plate for ease of mounting into an optical train. It has a 4 mm clear aperture and a 520 nm to 595 nm wavelength range.
Технические характеристики
- Center Wavelength 532 nm
- Spectral Range 520-595 nm
- Clear Aperture 4 mm
- Isolation >32 dB
- Transmission ≥ 90%
- Damage Threshold > 500 W/cm2 CW
- Pulse Damage Threshold > 1 J/cm2 @ 10 ns
- Material TGG-based
- Polarization State Input Polarization 0° +/- 3°
Output Polarization 90° +/-3° - Polarizer Type PBS Cube
- Operating Temperature 22° C
- Storage Temperature -20 °C to 60 °C
- Operating Humidity
