Epicicloidal reduction gearbox with a sintered steel frame, anodized aluminium flange, output shaft supported by two ball bearings Permanent greasing Max forces that may act on the output shaft: Axial 500 N Radial 600 N on the end of output shaft. Max speed advised at the reduction gear 4000 R.P.M. Life in standard condition 4000 hours. Right to be connected with IEC F 63 B 14 motors. Max use limit with standard biphases or triphases motors IEC 63 2 pole 0,25 HP Max- ratio 1/64 4 pole 0,17 HP Max- ratio 1/36 *Data related to gearboxes with reduced backlash (RHP).
Технические характеристики
CharacteristicsTypeepicyclicShaft orientationcoaxialTorque50 — 100 NmShaft configurationsolid-shaftOther characteristicsindustrial, with flange, flange, for electric motorsRotational speed
4,000 rpm (25,132.74 rad.min-1)
Power
Max.: 0.25 ch (0.25 hp)
Min.: 0.17 ch (0.17 hp)
