Технические характеристики
| Input lens mount | C-mount |
|---|---|
| Input surface size | Dia.25 mm |
| Photocathode | GaAsP |
| Number of MCP stages | 1 |
| Output phosphor screen / window | P43 / FOP |
| Spectral Response (Short) | 280 nm |
| Spectral Response (Long) | 720 nm |
| Cathode luminous sensitivity | 700 μA/lm |
| Cathode radiation sensitivity | 214 mA/W |
| Cathode quantum efficiency | 50 % |
| Luminous gain | 2.2 x 104 (lm/m2)/lx |
| EBI | 3.0 x 10-12 lm/cm2 |
| Central limitting resolution | 57 Lp/mm |
| Image magnification | 1 |
| Gate minimum ON time | 5 ns |
| Gate maximum repetition | 30 kHz |
| Power supply voltage (using AC adapter) | 100 V to 240 V |
| Operating ambient temperature | 0 ℃ to +40 ℃ |
| Operating ambient humidity and storage humidity | Below 70 % |
