These thermostats are ideally suited for use In hazardous atmospheres, gas or liquids. Marking : .11 2 G Ex d IICT1 toT6 . Breaking capacity on resistive load : -5/8” models: 10 A at 115 VCA, 5A at 230 VCA, 2 A at 115 VCC. -1/2” models: 5 A at 115 VCA, 3 A at 230 VCA, 1 A at 115 VCC. Aluminium alloy box with Integral ADF gland tor cables of mln.010 mm, max.019 mm. Option : Epoxy-coated box. Earth terminal. Protective resistance. Usable in hazardous areas (ambient temperature mini -20°C, relative humidity 95 % maximum).
Технические характеристики
CharacteristicsHeating technologyelectromechanicalProtection levelexplosion-proof, for harsh environmentsTemperature
Max.: 315 °C (599 °F)
Min.: -70 °C (-94 °F)
Switching power: current
1 A, 2 A, 3 A, 5 A, 10 A
Switching power : voltage
115 V, 230 V
