IQT3F Pro electric modulating actuators are capable of multi-turn, rising output, linear output and direct rotary output. Includes special fast switching control inputs for hardwired control. Electrical Supply: 3-phase 1-phase DC Actuator Type: Full turn Isolating / regulating duty and modulating duty Duty Cycle: Up to 1,800 starts per hour S4 / Class C Torque Range: A = Torque range 20 to 250 Nm (14.8 to 184.5 lbf.ft) B = Torque range 20 to 3,000 Nm (14.8 to 2,214 lbf.ft) L = Thrust range 7.5 to 75.8 kN (1,693 to 17,036 lbf)
Технические характеристики
CharacteristicsTypeelectricMovementrotary, linearPhasethree-phase, single-phaseOther characteristicsmodulating, DCTorque
Max.: 3,000 Nm (2,212.69 ft.lb)
Min.: 20 Nm (14.75 ft.lb)
Actuator force
Max.: 76 kN
Min.: 8 kN
