The use of electric drives instead of pneumatic or hydropneumatic driven cylinders is a modern advancement in assembly technology. SCHMIDT Technology combined its proven rack & pinion and ServoPress experience to create a new electric drive technology, providing high efficiency, full programmability and precision in a flexible pressing system. SCHMIDT® ElectricPress 43, without force-displacement monitoring, is the alternative to pneumatic presses for use in the small to medium force range, e.g. in the industrial branches: Automobile construction / motor vehicle Ignition key assembly Lock assembly Electronics, electrical engineering Mounting of spacer bolts in the circuit board Assembly of cable / cable lug Textile and leather Beading ring eyelets in leather straps Punching / cutting of textile contours ≤ 1 µm resolution drive control 200 mm/s ram speed (max.)
Технические характеристики
CharacteristicsOperationelectricFunctionpunching, cutting, assemblyStructureramOther characteristicsdigital, leatherForce
2.5 kN, 4 kN
Stroke
100 mm (4 in)
Table width
150 mm (6 in)
Table length
180 mm (7 in)
