Pipe bevelling system with inner clamping, automatic feeding,wall thickness ≤ 75mm, clamping in pipe axis Robust portable pipe bevellers with automatic feeding. Total range Ø80 – 820 mm (3.14“ – 32.28“). Wall thickness ≤ 75mm. The machines are designed to straighten the front, create bevel and inner calibration of pipe diameter. The angle and shape of bevel is optional. When adjusted, the machine is able to get the ends of pipes rapidly and repeatedly ready for welding. Concentric inner clamping is the guarantee of perfect securing and centring of the machine. Clamping in pipe axis can be an advantage in specifically confined conditions. Option to select electric or pneumatic drive.
Технические характеристики
CharacteristicsOperationelectric, pneumaticTypeportableApplicationspipeOther characteristicswith automatic clamping system, with automatic feederPower
Max.: 2.5 kW (3.4 hp)
Min.: 0.5 kW (0.68 hp)
Rotational speed
Max.: 16 rpm (100.53 rad.min-1)
Min.: 9 rpm (56.55 rad.min-1)
