The M-ND20-A NewDamp Elastomeric Isolator supports 20-115 kg loads and is based on conical elastic elements providing for a softer lower load in the same envelope as the M-ND30-A. The M-ND20-A has a 83 mm height and a 114 x 114 mm base. It provides almost equal isolation in vertical and horizontal directions. By using custom profiled upper supports, these isolators can be easily tuned to particular load/frequency requirements. Metric breadboard microlock compatible.
Технические характеристики
- Load Capacity per Isolator 115 kg
- Minimum Isolator Load 20 kg
- Isolator Height 83 mm
- Interface Compatibility Breadboard, Microlock
- Base size 114 x 114 mm
- Natural Frequency, Vertical Max. 12 Hz
- Natural Frequency, Vertical Min. 9 Hz
- Natural Frequency, Horizontal Max. 10 Hz
- Natural Frequency, Horizontal Min. 8 Hz
