| Edmund Optics Model # | 59-870 |
|---|---|
| LUCID SKU: | EOC0160 |
| LUCID SKU: | EOC0160 |
| Focal Length | 16 mm |
| Field of View @ Max Sensor Format | 61.4mm 30.9° |
| Distortion(%) | |
| Working Distance | 100mm ∞ |
| Field of View, 1/2 Sensor: | 44.5mm 22.7° |
| Field of View, 1/3 Sensor: | 33.3mm 17.1° |
| Field of View, 2/3 Sensor: | 61.4mm 30.9° |
| Number of Elements (Groups) | 7 (6) |
| Type | Fixed Focal Length Lens |
| Maximum Length | 40.5 mm |
| Maximum Sensor Format | 2/3 |
|---|---|
| Coating | 425 675nm BBAR |
| Field of View, 1/1.8 Sensor | 50.1mm 25.5° |
| Field of View, 1/2.5 Sensor | 40.3mm 20.6° |
| Field of View, 1/4 Sensor | 24.9mm 12.8° |
| Aperture (f/#) | f/1.6 f/16 |
| Mount | C-Mount |
| Numerical Aperture NA, Object Side | 0.013 |
| Outer Diameter | 33.00 mm |
| Weight | 74 g |
| Fixing Knobs Bundled | 4 total: 2x normal, 2x recessed |
