Additional Features:
- Range 1: 0-70V, 0-30A
- Range 2: 0-80V, 0-26A
- Power: 2100W
- Programming Accuracy at 25°C ±5°C: Voltage: 0.04% + 80 mV, + Current: 0.1% + 25 mA
- Ripple & Noise 20 Hz to 20 MHz: Voltage RMS: 2 mV, Peak-to-Peak: 16 mV, Current RMS: 25 mA
- Overvoltage Protection-OVP and current Overcurrent Protection-OCP
- Standard Programming Language
- Remote Inhibit/Discrete Fault Indicator
The single output, 2000W GPIB Agilent E4356A provides dual range output, fast, low-noise outputs, analog control of output voltage and current, fan-speed control to minimize acoustic noise, and built-in measurements and advanced programmable features.
To maximize the available power from this 2100 W power supply, the output automatically switches between two ranges: 0 to 70 V at up to 30 A and 0 to 80 V at up to 26 A. In either range, when operating at high voltages, maximum output power is available.
The E4356A generates less than 2 mV RMS at 80 V output. This noise specification is as much as ten times lower than typical ATE power supplies in the 2000 Watt power range.
Технические характеристики
| Manufacturer | Agilent, HP, Keysight |
|---|---|
| Condition | Used |
| Current | 26 A |
| Voltage | 80 V |
| Power | 2.1 kW |
