Description
The Dwyer LPCP Low Pressure Calibration Pump is a low air pressure source with the ability to easily adjust and stabilize. This hand pump possesses a pressure range of ± 5.8 psi, uses air as the media, and can adjust the pressure easily with great stability. The LPCP is made up of quick connectors for fast instrument connect and disconnect. The pump has a heat-insulator between the cover and pressure chamber to lessen the heat effect during the micro-pressure calibration. The adjusting resolution is up to 0.01 Pa (0.0001 mbar). These features make the LPCP ideal for calibrating pressure transducers, precision pressure gauges, and other pressure instruments.
Технические характеристики
Features
- Portable pressure source
- Range: 5.8 psi (0.4 bar) vacuum to 5.8 psi (0.4 bar) positive pressure
- Pressure resolution: 0.01 Pa, 0.0001 mbar
- Process Connection: M20x1.5, 1/4′ NPT with included adapters
- Heat insulation and heat preservation, no negative side effects from temperature changes
- Open structure for convenient maintenance of the pumps
- Easy to operate: pressure is precisely set with a simple turn of the handle, allowing you to calibrate gages quickly and accurately
- Great seal performance: minimum leakage
