Description
The Dwyer 1000E Pressure Switch has the same rugged construction as used in Series 1000W plus explosion-proof design are combined in this new unit. UL listed for Class I, Groups A, B, C & D, Class II, Groups E, F & G. The Bellville spring movement permits mounting of control in any position and helps prevent contact chatter. High over-pressure protection and vibration resistance are also featured.
Applications for the 1000E include:
- Chemical, petroleum, food and drug processing industries
- Process and industrial applications
Технические характеристики
Features
- Pressure ranges to 1400 psi
- Visible setpoint
- Fixed deadband
- Spring movement design
- Pressure limit: 3000 psig (206.8 bar)
- Explosion proof enclosure rating
- SPDT snap switch
