Технические характеристики
| Features | For Vacuum UV to UV |
|---|---|
| Type | Biplanar Phototube |
| Spectral Response (Short) | 115 nm |
| Spectral Response (Long) | 320 nm |
| Spectral Response (Peak) | 200 nm |
| Tube Diameter | Dia.63 mm |
| Photocathode Area Min. | Dia.20 mm |
| Photocathode Material | Cs-Te |
| Input Window Type | Head-on |
| Window Material | MgF2 |
| [Maximum Ratings] Anode Supply Voltage | 3000 V |
| [Maximum Ratings] Peak Cathode Current | 1 A |
| [Maximum Ratings] Input Light Energy Density | 0.125 W/mm2 |
| [Maximum Ratings] Average Cathode Current | 50 μA |
| Luminous Sensitivity Typ. | 15 mA/W (at 254 nm) |
| Radiant Sensitivity at Peak Typ. | 25 mA/W |
| Time Response Rise Time Typ. | 270 ps |
| Time Response Fall Time Typ. | 100 ps |
