Universal oven Um UN75mplus The heating oven Um is a Class I medical device. Standard delivery Universal oven Um This universal oven made of high-quality hygienic, easy to clean stainless steel leaves nothing to be desired in terms of ventilation technology, control technology, overtemperature protection and perfectly tuned heating technology. Control technology ControlCOCKPIT: TwinDISPLAY. Adaptive multifunctional digital PID-microprocessor controller with 2 high-definition TFT-colour displays. Language setting: German, English, Spanish, French, Polish, Czech, Hungarian Timer: Digital backwards counter with target time setting, adjustable from 1 minute to 99 days Function HeatBALANCE: adapting the distribution of the heating performance of the upper and lower heating circuit from -50 % to +50 % Function SetpointWAIT: the process time does not start until the set temperature is reached Calibration: three freely selectable temperature values adjustable parameters: temperature (Celsius or Fahrenheit), air flap position, programme time, time zones, summertime/wintertime Ventilation Convection: natural convection Fresh air: Admixture of pre-heated fresh air by electronically adjustable air flap Vent: vent connection with restrictor flap Communication Documentation: programme stored in case of power failure Programming: AtmoCONTROL software on a USB stick for programming, managing and transferring programmes via Ethernet interface or USB port
Технические характеристики
CharacteristicsFunctiondryingConfigurationchamberHeat sourceelectricAtmospherenatural convectionOther characteristicsinox, digital, laboratoryMaximum temperature
Max.: 300 °C (572 °F)
Min.: 20 °C (68 °F)
Capacity
74 l (19.5 gal)
Width
400 mm (15.75 in)
Height
560 mm (22.05 in)
Depth
330 mm (12.99 in)
