The LDP-3811-240V Precision Pulsed Current Source is specifically designed to drive low power laser diodes, the LDP-3811 is a microprocessor-controlled current source with two operational modes, CW or pulsed. Offering a dual range 200/500 mA output, it has the flexibility to meet a variety of lower power laser diode testing needs. The standard GPIB interface with trigger in/out functions allow complete system integration with other lab equipment, and improve the accuracy, ease, and speed of data gathering and remote measurement. The intuitive front panel allows easy adjustment of CW or pulsed operating modes and parameters. The LDP-3811 offers complete laser diode protection and safety features such as current limits and output shorting circuits, along with operational and power transient protection.
Технические характеристики
- Laser Current 0.5 A
- Laser Compliance Voltage 25 V
- Temperature Coefficient
- Computer Interfaces GPIB
- Power Requirements 240 VAC
- Laser Current Resolution 100 A
- Laser Current Accuracy ±0.5% of FS
- Laser Output Noise/Ripple Low Bandwidth
- Current Output 24 h Stability
- Current Output 1 h Stability
- Duty Cycle 0.01% to 100%
- Pulse Width 100 ns to 1 ms
- Pulse Repetition Rate 1 µs to 1 ms
- Rise/Fall Time
- Display Type 5-digit Green LED
- Weight 5.2 kg
