Lifting table on wheels with manual lifting With double pantograph Product BS130 C2 is a manual lifting table (with double pantograph) with lifting by means of a manual lever pump suitable for handling bags, drums and various goods. This type of trolley, being equipped with non-electrical components and in stainless steel, is particularly suitable for use in potentially explosive environments regulated by Atex regulations. In addition to the standard version, VEAB is able to supply customised lifting tables with dimensions and lifts specific to work requirements. We can also equip the tables with special accessories such as rollers or sliding balls, tilting tables, swivel tables, sides, to make the handling more and more ergonomic and less tiring. • Available in both stainless steel and painted steel. • Tailored solutions — Custom design for your needs. • Reliable experience — Over 30 years of successes. • ATEX certification — Possibility to ATEX conversion. • Customer support — Immediate answers and solutions. Technical specifications Model — BS130 C2 Capacity — 400 kg Weight — 230 kg Drive — Manual traction Lifting — Manual with lever pump Length — 1300 mm Width — 600 mm Max. lifting height — 450/1500 Warranty (years) — 2
Технические характеристики
CharacteristicsTechnologydouble-scissorOperationmanualTypemobileOther characteristicscustomCapacity
400 kg (881.8 lb)
Lifting height
Max.: 1,500 mm (59 in)
Min.: 450 mm (18 in)
Weight
230 kg (507.06 lb)
