Air-operated double diaphragm pumps BOXER 252 diaphragm pumps are characterized by exceptional performance, power and strength, making them ideal for pumping liquids with high apparent viscosity even if containing suspended solids. ■ Product designed and constructed in Italy ■ PATENTED stall-prevention pneumatic circuit ■ Operates with non-lubricated air ■ SELF-PRIMING ■ Dry operation ■ ATEX certification for ZONE 1 — ZONE 2 ■ IECEx certification ■ Adjustable operating speed ■ Extremely versatile ■ Suitable for pumping liquids with high viscosity and demanding applications ■ Possibility of pumping fluids containing suspended solids ■ Possibility of suspended installation ■ Suitable for continuous use
Технические характеристики
CharacteristicsFluidwater, for chemicals, for biodieselOperationair-drivenPrimingself-primingTechnologydouble-diaphragmMobilitystationaryDomainindustrial, for the chemical industry, for water treatment, for oil industry applications, for the mining industry, for the metallurgical industry, for the textile industry, for the glass industryApplicationstransferMaterialstainless steelProtection levelATEXFlow
Max.: 340 l/min (89.8185 us gal/min)
Min.: 220 l/min (58.11785 us gal/min)
Pressure
Max.: 8 bar (116.03 psi)
Min.: 2 bar (29.008 psi)
Head
Max.: 80 m (26205)
Min.: 0 m (000)
Fluid temperature
Max.: 95 °C (203 °F)
Min.: 3 °C (37.4 °F)
Output diameter
40 mm (1.6 in)
Length
254 mm (10 in)
Width
417 mm (16.42 in)
Height
538 mm (21 in)
Weight
2,620 g (92.42 oz)
