Description
Specification:
- Temperature Range: 5 °C to 85 °C (max. 18 °C below ambient)
- Temperature Accuracy: ±0.5 °C
- Temperature Stability: ±0.1 °C
- Temperature Precision: ±0.1 °C
- Column Capacity: Up to 6 columns, max. 30 cm length
- Heat-up Time: Typically 15 minutes 20 °C to 50 °C
- Cooldown Time: Typically 18 minutes 50 °C to 20 °C
- Control: All functions software controlled via USB
- I/O interfaces: 2 digital inputs, 2 programmable relay outputs
- Switching valves: 1 or 2 thermostatted valves (2-position, 6-port, 2-position, 10-port, or 6-position, 7-port)
- Watted parts
- Stainless steel (1.4571, 316L), PEEK, Waste line: PTFE
- Column switching valve (stainless steel): Vespel and DuraLife
- Column switching valve (biocompatible): PEEK
- Column switching valve (6-position, 7-port): Titanium
- Safety features: Humidity sensor and gas sensor. Temperature control and temperature sensors
- User input/display
- LCD-indicating system parameters
- Standby button
- 3 LEDs for status monitoring (Power, Connected, Status)
- 4 function keys for operation during initial installation and maintenance
- GLP features: Electronic identification system for 4 columns. In Chameleon: Full support of automatic equipment qualification (AutoQ) and System System Wellness monitoring. All system parameters are recorded in the Chromeleon Audit Trail.
- Power requirements: 100 – 120 V, 60 Hz, 200 – 240 V, 50 Hz, max. 150 VA
- Environmental conditions: Indoor use only, 10 to 35°C (50 to 95°F) operating temperature range, 80% relative humidity (non-condensing), Overvoltage category 2, Pollution degree 2.
- Dimensions (H x W x D): 17 x 42 x 51 cm (6.7 x 16.5x 20 in)
- Weight: 13.2 kg (29.0 lbs)
