The MD 9060 ranks among the most accurate multimeters with a large bandwidth and very high resolution. Metrel MD 9060 is equipped with a built-in VFD feature that makes the instrument capable of measuring the true values in accordance with frequency, large 2-line 500.000 counts LCD display, fast data acquisition and transfer (via optical interface), CAT IV / 1000 V, TRMS current and voltage measurement, conductance measurement and fast one-handed operation. MD 9060 has a wide range of extra features, including data hold, memory, min / max, average, differential, peak, peak / peak with extra fast 1ms response time, auto power off, frequency filter, reset and relative function. The MD 9060 is the ideal choice for demanding measurement tasks in industry, in the laboratories and in everyday repair and maintenance practice. Measuring functions • TRMS AC, DC voltage measurement, • TRMS AC, DC current measurement, • Capacitance measurement, • Resistance measurement, • Diode test, • Mains supply frequency measurement, • Frequency of digital signals measurement, • Continuity test (acoustic signalling), • Conductance measurement, • Temperature measurement. Key features • TRMS: accurate readings on sinusoidal and non-sinusoidal signals. • VFD: feature makes the instrument capable of measuring the true values in accordance with frequency. • Auto-ranging: user can switch between auto and manual ranging. • Temperature measurement: measures T1, T2 and T1 + T2 temperature in Celsius and in Fahrenheit. • Lead alert: incorrect lead connection alert. • Relative zero mode: relative function for comparing the difference between signals or removing background noise.
Технические характеристики
CharacteristicsTypedigitalFormportableMax voltage1000 VMax current10 ASafety ratingcat IVAdditional featuresfrequency, with thermometerApplicationsindustrialOther characteristicstrue RMS, AC, DCMax DC voltage
Max.: 1,000,000 mV
Min.: 500 mV
Max AC voltage
Max.: 1,000,000 mV
Min.: 500 mV
Max DC current
Max.: 10,000 mA
Min.: 0.5 mA
Max AC current
Max.: 10 A
Min.: 0.6 A
Max resistance measure
Max.: 50,000,000 Ohm
Min.: 500 Ohm
Max capacity measure
Max.: 25,000,000 nF
Min.: 50 nF
Max frequency measure
Max.: 200,000 Hz
Min.: 10 Hz
Process temperature
Max.: 1,000 °C (1,832 °F)
Min.: -50 °C (-58 °F)
Weight
635 g (22.4 oz)
