The SIGEA digital controls are available in two versions, a single axis and a multi axis, the characteristics of which you will find below. DIGITAL MONO AX CONTROL FOR MOTORIZATION STEP BY STEP OR BRUSHLESS IN BOX SIGEAX 116BR / PP10V3 / 0 4000-axis / t axis card Presentation in IP65 stainless steel box Control 1 axis stepper motor 4A-220V 240 V 500 V power supply Programming by RS 232 (Pocket or PC) User interface dedicated to inkjet 8 entries (departure, origin, etc …) 8 outputs (alarm, end of cycle, top, etc …) Local control by buttons DIGITAL MULTI-AXIS CONTROL FOR MOTORIZATION STEPPER OR BRUSHLESS IN BOX SIGEAX 416BR/PPV2/6 Built-in rack 19 inches ventilated depth 600 mm The connections are made on the back side. Basic presentation rack 19 ‘6U 84TE shielded CE conforms: weight about 25Kg. 240V 50Hz mono power supply 24 Inputs 24v / 24 Outputs 24v 100mA (No. I / O = 48) 1 to 4 15A Brushless Drives or 1 to 3 30A / 1 to 4 Frequency Inverters (1 to 6 A, 4 to 10 A) for Stepper Motor Option: External connection strip for extension 24E / 24S. Transforms 8S into 2A relay
Технические характеристики
CharacteristicsMotor typestepper, brushlessOther characteristicsdigital, single-axis, multi-axis, RS-232, housed, wall-mountedInput voltage
Max.: 500 V
Min.: 240 V
Current
Max.: 30 A
Min.: 1 A
