AMT-7000 is a highly accurate multipurpose power system recorder equipped with various functions to monitor and record electric power system such as Digital Fault Recorder(DFR), Dynamic Disturbance Recording (DDR), Phasor Measurement Unit (PMU) and Sequence of Event Recording (SER) . FEATURES Multiple functions ・Digital Fault Recording (DFR) ・Dynamic Disturbance Recording (DDR) ・Phasor Measurement Unit (PMU) ・Sequence of Event Recording (SER) 256spc sampling ・Sampling by 256 spc highly accurate measurement and recording. Multiple input elements ・Up to 64 analog inputs and 128 digital inputs. IEC61850 Compliant ・Complies with IEC61850 and can subscribe GOOSE message from station bus, trigger DFR and record to DFR and SER. COMTRADE Format The data format is in accordance with IEEE Std C37.111-2013 (COMTRADE). Human machine interfaces ・5.7 inch color LCD with touch panel is equipped. ・Build-in web server provides browser based HMI. Various time correction method ・GPS, IRIG-B, NTP PC software ・Data manager automatically receives data from the AMT-7000 and manages it. ・Waveform analysis software supports various analysis such as detailed waveform display, waveform composition.
Технические характеристики
CharacteristicsOptionsdigital
