The MD 9240 is a high-quality and extremely easy to handle power clamp meter. The MD 9240 enables TRMS AC current measurement up to 1000 A, AC and DC voltage measurement, single-phase power analysis, temperature measurement and more. As a result the current clamp meter is suitable for maintenance and checking of distribution systems, switchboards and motors or systems where the supply network is heavily contaminated with harmonics. Measuring functions • TRMS AC, DC voltage measurement, • TRMS AC current measurement, • Frequency measurement, • Resistance measurement, • Continuity test, • Temperature measurement, • Power parameters measurement. Key features • TRMS: accurate measurements on sinusoidal and non-sinusoidal signals. • Jaw size: 45 mm. • High current: measures up to 1000 A AC. • Autocheck function: automatic detection of AC voltage, DC voltage or AC current. • Power: measures various power parameters (active, reactive, apparent power, PF). • Temperature: measures temperature in Celsius up to 300 °C and in Fahrenheit up to 572 °F. • PC Link: test results can be downloaded to the computer via the optional PC software. • Data Hold: data hold feature freezes the display for later view. • Peak Hold: peak hold feature displays maximum RMS value of surge voltage or current. Technical data • Dimensions (w x h x l): 78 x 40 x 224 mm • Mass (without accessories): 224 g
Технические характеристики
CharacteristicsTypedigitalFormportableMax voltage600 VMax current1000 ASafety ratingcat IIIAdditional featuresfrequency, with power measurement, with data loggerOther characteristicsTRMS, AC, DCMax DC voltage
Min.: 0.1 V
Max.: 600 V
Max AC voltage
Min.: 0.1 V
Max.: 600 V
Max AC current
Min.: 0.01 A
Max.: 1,000 A
