The ME 16C VARIO select pump is an excellent solution for continuous, oil-free pumping of corrosive gases and vapors. With pump heads constructed from chemical resistant fluoroplastics, and the proven PTFE sandwich diaphragm, our chemistry rated pumps feature unrivaled service intervals. The integrated VACUU·SELECT controller provides an easy-to-use, application based interface that covers all common lab applications. The VACUU·SELECT controller has you covered. Use manual set-point-control for simple processes, run fully automated distillations, or create your own application with simple drag-and-drop editing. For solvent evaporation, the VACUU·SELECT controller continuously detects the boiling point and automatically adjusts the vacuum process to meet process requirements. With VARIO control, the pump runs only as fast as is necessary. This extends the maintenance intervals and makes the pumping unit quiet. Performance features VACUU·SELECT vacuum controller with graphical user interface and predefined applications simplifies work in the laboratory automatic boiling point detection and adjustment of the vacuum for short process times suitable for evaporation of large quantities of low-boiling solvents extraordinary diaphragm life for minimum operational and servicing costs
Технические характеристики
CharacteristicsTechnologydiaphragmLubricationoil-freeSupply voltage230VACNumber of stagessingle-stageApplicationsfor laboratories, for the chemical industry, chemical processOther characteristicschemical-resistantUltimate vacuum
70 mbar, 100 mbar (1.02 psi)
Flow rate
19.3 m³/h (681.57 ft³/h)
Power
530 W (0.72 hp)
Operating temperature
Max.: 60 °C (140 °F)
Min.: -10 °C (14 °F)
Length
533 mm (21 in)
Width
260 mm (10.24 in)
Height
450 mm (18 in)
Noise level
47 dB
Weight
28.9 kg (63.71 lb)
