Diaphragm compressor is a special structure positive displacement compressor. The cylinder does not need to be lubricated, the sealing performance is good, the compression medium does not contact any lubricant, there is no pollution, and the compression purity can reach 99.999%. It is especially suitable for the compression, transportation, and bottling of high-value rare gases and highly corrosive, toxic, explosive, and radioactive gases. For example, H2、He、Ar、C2H4、F、HS、CL、SiH4、NF Diaphragm compressor cylinder has good heat dissipation, simple and efficient structure, high pressure can be achieved by two-stage compression, and at the same time, it can be close to isothermal compression. Therefore, it is used in industrial gas, food and medicine, petrochemical industry, aviation nuclear power, military equipment, scientific research, and testing, etc. The field is widely used. Piston travel: 70-180mm Max.piston force: 10KN-90KN
Технические характеристики
CharacteristicsTechnologydiaphragmTypeairPower sourceelectrically-poweredPortabilitystationaryApplication domainindustrial, for medical applications, for food applications, for the petrochemical industry, for scientific research, for testingApplicationsgasOther characteristicshigh-pressure, two-stage, isothermalPressure
70 MPa
Flow
Max.: 500 m³/h (17,657.33 ft³/h)
Min.: 0.5 m³/h (17.66 ft³/h)
Power
Max.: 45 kW (61.18 hp)
Min.: 2.2 kW (2.99 hp)
