Технические характеристики
| Package | Metal |
|---|---|
| Package Category | TO-8 |
| Cooling | One-stage TE-cooled |
| Spectral response range | 0.32 to 1.67 μm |
| Detector (1) | Si |
| Photosensitive area (1) | 2.4×2.4 mm |
| Peak sensitivity wavelength (typ.) (1) | 0.94 μm |
| Photosensitivity (typ.) (1) | 0.45 A/W |
| Detector (2) | InGaAs |
| Photosensitive area (2) | φ0.5 mm |
| Peak sensitivity wavelength (typ.) (2) | 1.55 μm |
| Photosensitivity (typ.) (2) | 0.55 A/W |
| Measurement condition | Typ., Ta=25 ℃, unless otherwise noted |
