Flat DC-Micromotors and DC-Gearmotors Precious-metal commutated DC-Micromotors with uniquely flat coil technology with three flat, self-supporting copper windings used in the SR-Flat series form the basis for drive systems in applications where space is extremely limited. With their powerful rare-earth magnets, the motors deliver a continuous output of 0.8 W to 4 W and at the same time have only minimal inertia. The motors are available with integrated gearheads and optical encoders – both with an extremely flat design matched to the motors. When combined with integrated gearheads and encoders, they provide a very compact drive system with increased output torque. Advantages — Extremely flat design. Lengths ranging from 6 mm to 19 mm — 4-pole design — Minimal moment of inertia — Integrated spur gearheads of minimal length with high gear ratio are available — Available with integrated optical encoders
Технические характеристики
CharacteristicsAC/DCDCTypebrushedConfigurationmicro, flatNumber of poles4-polePower
Max.: 4 W (0.005 hp)
Min.: 0 W (0 hp)
Torque
Max.: 0.003 Nm (0.0022 ft.lb)
Min.: 0.0004 Nm (0.0003 ft.lb)
Rotational speed
Max.: 15,500 rpm (97,389.37 rad.min-1)
Min.: 5,900 rpm (37,070.79 rad.min-1)
Diameter
15 mm, 26 mm (0.59 in)
