The EA090A series brushless motor is a high torque model brushless motor designed in a NEMA 34 package with an IP65 rating. It is offered in 3 motor lengths with continuous torque from 1.8 — 4.6 Nm. Features: Speeds up to 6,000 RPM possible DC bus voltage up to 325 Vdc NEMA 34 package Five standard windings 4 Pole Rare Earth design
Технические характеристики
CharacteristicsAC/DCDCTypebrushlessProtection classIP65ConfigurationNEMA 34Number of poles4-polePower
Max.: 1,800 W (2.447 hp)
Min.: 900 W (1.224 hp)
Torque
Max.: 4.6 Nm (3.3928 ft.lb)
Min.: 1.8 Nm (1.3276 ft.lb)
Rotational speed
6,000 rpm (37,699.11 rad.min-1)
Diameter
90 mm (3.54 in)
