Lawn Mower Cutting DC Motors 52ZWN, 57ZWN Typical applications: Lawn Mower Robot Drive DC Gear Motors & Cutting DC Motors Robot Lawn Mower Drive Motor General Technical Specifications: Motor Type: Brushless / brushed DC gear motor Operating Voltage: 12 ~ 24V DC Rated Speed: 20 ~ 70rpm Rated Torque: 1.0N.m ~ 5.0N.m Life time: 2000 ~ 5000 hours Typical Motor Type: 36mm, 42mm diameter long life brushless DC planetary gear motors 36mm, 42mm diameter brushed DC planetary gear motors (optional encoder) Robot Lawn Mower Cutting Motor General Technical Specifications: Motor Type: Brushless / brushed DC motor Operating Voltage: 12 ~ 24V DC Rated Speed: 3000 ~ 8000rpm Rated Torque:0.10 ~ 0.5N.m Output Power: 18W ~ 100W Life time: 2000 ~ 10000 hours Typical Motor Type: 42mm square brushless DC motor, 52mm, 57mm diameter brushless DC motor
Технические характеристики
CharacteristicsAC/DCDCTypebrushlessVoltage 18 VProtection classmaintenance-freeApplicationsfor robotics, agricultural, for battery-powered systems, for lawn-mowers, for robotic lawnmowerOther characteristicscustomPower
Max.: 100 W (0.136 hp)
Min.: 18 W (0.024 hp)
Torque
0.11 Nm (0.0811 ft.lb)
Rotational speed
4,500 rpm (28,274.33 rad.min-1)
Max.: 5,300 rpm (33,300.88 rad.min-1)
Min.: 0 rpm (0 rad.min-1)
Diameter
51 mm, 52 mm (2.01 in)
