Bayonet NCC Female panel mount connector, Contacts: 8, unshielded, solder, IP67 Connector design — Female panel mount connector Version — Connector socket straight Connector locking system — Bayonet Termination — solder Degree of protection — IP67 Cross-sectional area — 0.25 mm² / AWG 24 Temperature range from/to — -25 °C / 85 °C Tightening torque screw nut — 0.8 Nm Mechanical operation — > 5000 Mating cycles Weight (g) — 4.47 Customs tariff number — 85369010
Технические характеристики
CharacteristicsTypedataFormatDINShapecircularConnection typefemale, bayonetMaterialpolyamideProtection classIP67Other characteristicsminiature, panel-mountPrimary current
2 A
Voltage
175 V
