Connector locking systemMicro Push-Pull Terminationsolder Wire gauge (mm)0,14 mm² Wire gauge (AWG)26 Cable outlet3,0 — 4,0 mm Degree of protectionIP67 Mechanical operation> 1000 Mating cycles Upper limit temperature80 °C Lower limit temperature-40 °C Rated impulse voltage1500 V Pollution degree2 Overvoltage categoryII Insulating material groupII Volume resistivity≤ 8 mΩ Contact materialCuSn (bronze) Contact platingAu (gold) Contact body materialPA Customs tariff number85369010 Weight (g)2.815
Технические характеристики
CharacteristicsTypedataFormatDINShapecircularConnection typefemale, push-pullMaterialpolyamideProtection classIP67Other characteristicssubminiature, microPrimary current
1 A
Voltage
125 V
