Use: for self-supporting doors (without external frame) made of glass with a thickness of 4-6 mm or Plexiglas panels with a thickness of 6-8 mm. Material AISI316 stainless steel hinge and plate, AISI303 stainless steel pin, AISI304 stainless steel screws, AISI303 stainless steel anti-friction washers, black polyethylene bushings and PVC seals (if provided). State of supply hinge complete with 2 M8x20 hexagon socket countersunk head screws and 2 M8x20 socket head screws in AISI304 stainless steel. Only for the glass version: 2 bushings and 2 seals, 1 mm thick.
Технические характеристики
CharacteristicsTypeconcealedMaterialstainless steelInstallationscrew-inOpening angle180°Applicationsglass doorOther characteristicslockingLength
122.8 mm (4.835 in)
Width
56 mm (2.205 in)
