Series MX SAFEMAX solenoid valves are equipped with an integrated sensor that detects the position of the spool and enables to quickly exhaust the system in case of emergency. The single channel valve is classified in category 2 and can reach Performance level D. The double channel valve is classified in category 4 and can reach Performance level E. Please note: the safety valve is not sufficient, alone, to guarantee the safety function. Its setup requires the use of a monitoring device. The Machinery Directive (MD) 2006/42 / EC establishes the safety requirements that a machine must respect in order to protect the health of people during its use. Series MX SAFEMAX solenoid valves comply with ISO 13849-1, regarding the safe design of control systems that perform safety functions. Construction modular, compact, spool-type Materials see TABLE OF MATERIALS on the following page Ports G1/2 Mounting in-line, wall-mounting (by means of clamps) Medium Filtered air in class 7.4.4 according to ISO 8573-1. In case lubricated air is used, we recommend ISOVG32 oil and to never interrupt lubrication.
Технические характеристики
CharacteristicsFluidfor compressed airBody materialaluminumOther characteristicscompact, in-line, 3/2, quick, modularControlled pressure
Min.: 0.5 bar (7.3 psi)
Max.: 10 bar (145 psi)
DN
0.5 in
