The new Kontron COMe-mBT10 COM Express® mini Computer-on-Module family (55 mm x 84 mm) with Type 10 pin-out is equipped with Intel® Atom® processor E3800 or Intel® Celeron® processors. Seven module variants are included in the range, offering wide scalability from low-power single-core Intel® Atom™ (1.46 GHz / 5 W TDP) processor performance for energy-sensitive applications through to genuine quad -core Intel® Atom™ (4x 1.91 GHz/ 10 W TDP) and Intel® Celeron® (4x 2.42 GHz / 10 W TDP ) processor performance in high-end applications). The new Intel® Gen 7 HD graphics integrated on the SoC offer up to three times more graphical power, including DirectX 11, Open GL 3.1, and OpenCL 1.1 support for two independent displays with 1x DP++ (DP/HDMI/DVI) up to 2560×1600@60Hz and 1x Single Channel LVDS 18/24bit with DPtoLVDS up to 1920×1200 (and optional eDP).. New video HD technology additionally enables brilliant video reproduction and stereoscopic 3D viewing for an immersive user experience. The modules come with options for data memory: two SATA II 300 Mbps interfaces or versions with additional eMMC memory (up to 64 GB). In addition to having two serial ports, they include Super Fast USB 3.0 interfaces, up to eight USB 2.0, Gigabit Ethernet, plus three Gen 2 PCI-Express x1 lanes for customer specific expansions. Specifications Intel® Atom® E3800 & Celeron® Series Up to 4GB DDR3L memory down (ECC optional) 1x USB 3.0, up to 7x USB 2.0, 1x USB client (optional), eMMC Flash (optional), 2x SATA, SD-Card Commercial & Industrial Grade Temperature
Технические характеристики
CharacteristicsForm factorCOM Express MiniProcessorIntel® Celeron®, Intel® Atom E3800, x86PortsUSB 2.0, Ethernet, USB 3.0, SATA, DDR3 SDRAMOther characteristicsembedded, extended temperature range
