ELECNC-1530 5×10 ATC CNC Router with Rotary Device is a combination of 3 axis CNC, 4 axis CNC, ATC CNC and rotary device for wood carving and engraving. The automatic tool change function greatly saves manual tool changing time and increases work efficiency. So fewer operator will be needed to watch and assist the CNC machine’s work. HSD air cooling spindle can swing 180 degrees and the speed of spindle can reach up to 24000RPM. The Carousel type tool magazine can carry 8 sets of tools and manage to change tools automatically in the engraving process. Removable rotary device saves much more space and increases work flexibilit Application The rotary axis CNC router has a rotary device installed along whether the X-axis or the Y-axis. It is very suitable for engrave cylindrical workpieces, such as building columns, stair handrails, table and chair legs, and other circle or cylindrical parts. Besides, based on the spindle the rotary axis CNC router adopts, it can achieve different processes. If a rotating spindle is installed, this rotary axis CNC router can complete all the work that a 4 axis CNC router can do, like processing 3D workpieces. However, if the rotary axis CNC router adopts an ordinary spindle that cannot rotate, it can also realize the 2D cutting and engraving work.
Технические характеристики
CharacteristicsControl typeCNCNumber of axes3-axis, 4-axisNumber of spindles1-spindleTreated materialwoodApplicationsfor furnitureOther characteristicsCE, with automatic tool changer, deskX travel
1,300 mm, 1,500 mm, 2,100 mm (51 in)
Y travel
2,500 mm, 3,000 mm, 4,000 mm (98 in)
Z travel
400 mm, 500 mm, 600 mm, 700 mm (16 in)
