The ATC CNC router with an oscillating knife cutter can do things the same as ATC CNC machines, such as automatic tool changing without manual operation. It also has a powerful ability to cut leather, carpet, carton, wood, MDF, PVC, acrylic, cardboard, rubber, rorrugated box, foam due to the high efficiency oscillating knife. Equipped with the linear tool change function, 8 tools are automatically switched, saving time and improving efficiency. Adopting international imported components like big power and high precision servo motor and driver, the machine has a more precise machining accuracy and more stable operation. The high-power air cooling spindle has strong cutting capacity and excellent processing accuracy. Equipped with a vacuum & T-slot working table, it can fix the materials stably and firmly. Application The 3 axis ATC CNC router is an entry-level 3 axis CNC router with the automatic tool change function. The spindle can move along the X, Y and Z axis.So it is suitable for plate material processing, such as wooden boards, acrylic sheets, melamine boards, etc. Its principal functions include cutting, engraving, grooving, milling, drilling, pocketing, routing and boring. The oscillating knife is good at cutting flexible materials, such as rubber, fabric, leather, paper, etc.
Технические характеристики
CharacteristicsControl typeCNCNumber of axes3-axisNumber of spindles1-spindleTreated materialwood, acrylic, for PVC, for foam, leather, rubber, for plates, cardboard, for paper, fabricApplicationsdrillingOther characteristicswith automatic tool changer, portalX travel
1,300 mm, 1,500 mm, 2,100 mm (51 in)
Y travel
3,000 mm, 3,500 mm, 4,000 mm (118 in)
Z travel
200 mm, 300 mm, 400 mm, 500 mm, 600 mm (8 in)
