Application Area 1. Seasonal differences, different climate zones-your products must be able to withstand various temperatures during manufacturing, transportation, storage and use. The Temperature Humidity Chambers of Sonacme Technology will help you to test the effects of temperature and humidity on the characteristics, functions and service life of your products under accelerated conditions. 2. The Sonacme environmental test chamber and constant temperature and humidity test chamber with a wide range of applications allow you to control the temperature and humidity in the test chamber, ranging from -70°C to +180°C (temperature) and from 20% to 98% (relative humidity). Structural Features 1. The inner chamber material is made of SUS#304 stainless steel with 1.2mm thickness. Full welding structure, its sealing is very well and it’s not easy to get cracked. 2. The external material is made of cold-rolled plate with 1.5mm thickness, it has gone through brushing, polishing, painting treatment, it’s not easy to get scratched. 3. The insulation material is made of polyurethane foam with thicknessof 100mm. 4. The door seal adopts double silicon rubber sealing material. 5. The observation window is 4 layers of tempered glass, the size you can choose by yourself. 6. In addition, in order to prevent frosting on the observation window when running low temperature, we setup a heating wires inside to get it di-frosting.
Технические характеристики
CharacteristicsTypeclimatic, humidity and temperature, agingApplicationsfor materials testing machines, for automobiles, glass, for engine, for sensors, development, for the aeronautical industry, thermoplastic pipe, for electronic circuit boards, for small parts production, for altitude flight simulation, device, for auto lamp, for the pharmaceutical industry, for wires, for driving simulation, for electrical equipment, for composite materials, for test benches, for vehicles, European standards-compliant, international standards-compliant, for semiconductors, for motors, for aircraft, for specimen preparation, inspection, for windowsConfigurationcompact, floor-standing, on castersLight sourcewhite LEDOptions and accessorieswith temperature and climatic control, with window, stainless steel, low-temperature, for high temperatures, large, high-capacity, vertical, with constant temperature and humidity control, horizontal, with cyclical temperature/humidity control, large capacityCapacity
340 l (90 gal)
Temperature
Max.: 180 °C (356 °F)
Min.: -70 °C (-94 °F)
Length
950 mm (37.4 in)
Width
1,800 mm (70.9 in)
Depth
1,885 mm (74 in)
Power
600 W
