Circular air diffuser DCSQ series square horizontal panel

Circular diffuser with adjustable cones made up of concentric truncated cone profiles on a square panel, suitable for installation on false ceilings with 600x600mm panels. Height adjustable by means of an adjustment screw in order to change the direction of the air jet in relation to the required thermal conditions. CARATTERISTICHE • MATERIAL: aluminium and steel • SURFACE FINISH: epoxy powder coating resistant to impact and abrasion • COLOUR: RAL white 9010 glossy, 9016 glossy, 9003 mat. On request, coating in nonstandard RAL colours • FASTENING: by means of screws positioned on the diffuser neck • INSTALLATION HEIGHT: 2.7 – 6 m • USE: room cooling and heating GREEN BUILDING Contribute to obtain the credits of the major international rating systems for suistainable buildings: LEED: IP, EA, MR WELL: MATERIALS, COMMUNITY BREEAM: MAN, WST ADJUSTMENT Central cone in low position: optimal position in cooling conditions in order to have the largest horizontal diffusion radius without creating discomfort in the occupied area in rooms with an ideal height between 3 and 4 m. With this configuration, you have the best pressure drop, velocity and sound level conditions. The maximum temperature difference (DT) between the ambient air and the air flowing from the diffuser to obtain the optimal induction conditions is 12°C. Central cone in high position: optimal position for particularly high rooms up to 6 m and in heating conditions, as you obtain a vertical throw that resists the convective motion of the ambient air.
