Our peristaltic pumps are used in all fields of analytical and preparative chemistry and in production operations. In particular, they are used in instrumental analysis, biotechnology, bioanalysis, fluid chromatography, column chromatography, ICP, AAS, TOC as well as delivery and metering. The pump is driven by a stepper motor or AC motor and can be fitted with 1-6 channels. It is easy and functional to use. Specifications of Perimax 12 — Pump head with 12 rollers — Adjustable from 0.0017 ml / min to 20 ml / min — Individually adjustable channels — Accommodate a wide variety of tubing materials and sizes — Speed range: 33 rpm, — Right/left switchable direction of rotation — Power required: 110 — 230 Vac at 50 / 60 Hz, 70 W — Dimensions: 160 x 160 x 200 mm — Weight: 4 — 5 kg, depending on the number of channels Spetec offers tubing in any configuration of different diameter and quality with 1, 2 or 3 bridges. But also by the meter. Our tubings consist of these materials: — PVC Standard — Solvent Flex — solvent resistant — PU longlife — solvent resistant — Fluoro rubber (according to Viton®) — Santoprene® — Silicone
Технические характеристики
CharacteristicsFluidfor chemicalsOperationstepper motor-drivenTechnologyperistalticDomainlaboratoryOther characteristicshigh-speed, multi-channel, adjustableFlow
0.018 l/min (0.00476 us gal/min)
Power
70 W (0.1 hp)
