We introduce CUBE, an extremely compact, economical and versatile case palletizer. Thanks to its self-supporting structure with wheels, the equipment can be easily moved at the factory to service any line. In addition, it can be installed in places with low ceilings since it does not have a telescopic arm. Main advantages of the equipment: — Maximum speed: 8 boxes / minute. — Maximum box weight: 16 Kg. — Dimensions: 2480 x 1600 x 2750mm. — High ceilings are not necessary. — Self-supporting structure with wheels. — Maximum palletizing height 1950mm. — Built-in Stand-By system to improve energy efficiency. — Low consumption
Технические характеристики
CharacteristicsTypeCartesianProduct applicationsfor the food industry, for sacks, for boxes, for cans, for finished goods, package, for cans, for the food and beverage industry, for cardboard boxes, for bottle packs, for parcels, for chemicals, food carton, for food products, box, for cosmetic products, for chocolate products, coffeeSectorfor the packaging industry, bottling industryOther characteristicsautomatic, compact, for the chemical industry, for the food industry, medium-speed, low-speed, single-line, end-of-lineThroughput
Min.: 1 p/min
Max.: 10 p/min
8 p/min
Pallet width
Min.: 300 mm (11.81 in)
Max.: 800 mm (31.5 in)
800 mm (31.5 in)
Pallet length
Min.: 300 mm (11.81 in)
Max.: 1,200 mm (47.24 in)
800 mm (31.5 in)
Maximum palletizing height
Min.: 0 mm (0 in)
Max.: 1,950 mm (76.77 in)
1,950 mm (76.77 in)
Machine length
Min.: 2,400 mm (94.49 in)
Max.: 2,550 mm (100.39 in)
2,480 mm (97.64 in)
Machine width
Min.: 1,600 mm (62.99 in)
Max.: 1,800 mm (70.87 in)
1,650 mm (64.96 in)
Machine height
Min.: 2,650 mm (104.33 in)
Max.: 2,850 mm (112.2 in)
2,750 mm (108.27 in)
Electric powered
Min.: 340 V
Max.: 400 V
380 V
